Horizontal Balancing Machine H-IRB-500
Product Description
Precise Balancing Solution for Heavy Parts
The H-IRB 500 Horizontal Balancing Machine is a device designed for rotor weights ranging from 15 kg to 500 kg. This machine, which supports rotor diameters up to 1100 mm, ensures precision and reliability in dynamic and static balancing operations. The standard belt drive unit provides excellent performance for medium and large-scale rotors, while its durable structure offers long-term solutions for industrial needs.
The machine is equipped with advanced software capable of performing tolerance calculations in accordance with ISO 21940 standards. The user-friendly, Windows-based software allows operations on different rotor types without requiring recalibration. The CE-certified H-IRB 500 is delivered with installation and training support. Its application area can be expanded with additions like a drilling unit, depending on needs.
Technical Specifications
| Feature | Value |
|---|---|
| Maximum Rotor Weight | 500 kg |
| Minimum Rotor Weight | 20 kg |
| Maximum Rotor Diameter | 1100 mm |
| Minimum Shaft Diameter | 15 mm |
| Maximum Shaft Diameter | 240 mm |
| Motor Power | 5.5 kW |
| Drive Unit | Belt (Standard) |
| Bed Length | 2500 mm |
Application Areas
- Large rotors
- Turbines and fans
- Propellers
- Industrial drums and shafts
- Heavy and large-scale industrial parts
Why the H-IRB 500?
Discover the standout features of the H-IRB 500:
- Precise balancing for heavy and large parts
- Tolerance calculations in compliance with the ISO 21940 standard
- User-friendly interface and advanced software
- Durable structure and high performance
